Product Info
Category: Linear Bearings
Factory
Linear bearings are bearing elements for translation type motion. As in the case of rotary bearings, a distinction is drawn as to whether the forces occurring are transmitted by means of rolling or sliding elements. Each linear design has particular characteristics that make it especially suitable for particular bearing arrangements.
Linear Bearing Features
1. enable high precision linear motion on round shafts
2. sustain heavy loads with low noise and high stiffness
3. perform under almost any environmental conditions and load capacities to satisfy a wide range applications
| Product Name | Square flange linear motion bearing LMK8SUU for cnc linear shaft 8mm |
| Material | Chrome steel /Stainless steel |
| Tolerance Rating | ABEC-1,ABEC-3,ABEC-5 |
| Product Application | 1) Linear Bearing widely used in many precision equipment,like electronic equipment, tension tester and digital 3d coordinate measurement equipment etc. 2) Linear Bearing widely used in many machines,like multi-axis machine, punch, tool grinding machine, automatic cutting machine, printer, card sorting machine, ShiPinBao installed the sliding parts such as industrial machinery 3)Suitable for Countless Applications: Sliding Doors, Windows and Other Furnitures,etc. |
| Product advantage | 1) Low-cost and high loads linear motion system 2) High friction resistance of Linear Bearing can get high precision rotating in the smooth movement 3) With Carbon Steel Ball Bearing 4)With a High Load-Bearing Capacity 5)More Quietly than Metal Bearings 6)Low Noise, Stable Performance and Durable 7)Able to Work in Sub-Zero Temperatures and Have Low Rolling Resistance |
"LM" metric standard type linear bearing
"LME" inch standard type linear bearing
"UU" rubber seals on the both sides of the long type linear bearing
"OP" open type linear bearing
"AJ" adjustment type linear bearing
LM...UU: LM...(sylinder), LM...OP(open type), LM...AJ(clearance adustable)
LME...UU: LME...(sylinder), LME...OP(open type), LME...AJ(clearance adustable), LM...UU & LME...UU: Long type
KH: High-precision mini bearing
| Bearing Type | Ball | Weight | Inner size(dr) | Outer size(D) | Length(L) |
| LM6UU | 4 rows | 8g | 6mm | 12mm | 19mm |
| LM8UU | 4 rows | 16g | 8mm | 15mm | 24mm |
| LM10UU | 4 rows | 30g | 10mm | 19mm | 29mm |
| LM12UU | 5 rows | 31.5g | 12mm | 21mm | 30mm |
| LM13UU | 5 rows | 43g | 13mm | 23mm | 32mm |
| LM16UU | 5 rows | 69g | 16mm | 28mm | 37mm |
| LM20UU | 5 rows | 87g | 20mm | 32mm | 42mm |
| LM25UU | 6 rows | 220g | 25mm | 40mm | 59mm |
| LM30UU | 6 rows | 250g | 30mm | 45mm | 64mm |
| LM35UU | 6 rows | 390g | 35mm | 52mm | 70mm |
| LM40UU | 6 rows | 585g | 40mm | 60mm | 80mm |
| LM50UU | 6 rows | 1580g | 50mm | 80mm | 100mm |
| LM60UU | 6 rows | 2000g | 60mm | 90mm | 110mm |
| LM80UU | 6 rows | 4420g | 80mm | 120mm | 140mm |
Shenzhen Xinchangsheng Bearing Co., Ltd. was established in 2002. Located in Shenzhen, Guangdong Province, China, close to Hong Kong, is an important international air hub and foreign trade port city.
We specialize in the production of various types of bearings for 18 years, integrating design, manufacturing, research and development, production and testing equipment. Our company's leading products are deep groove ball bearings, thrust ball bearings, needle bearings, linear bearings, slewing bearings, etc. (including metric, inch systems and non-standard), suitable for household appliances, industry, medical, automotive and other industries.We also accept ODM and OEM.
Our company's products have high precision, long life, high quality and low price, perfect after-sales service, which are highly praised by customers at home and abroad. Our company has passed ISO9001 international quality system certification, and our products are sold all over the country. We have established long-term cooperative partnership with BYD and Wenhua Holdings, and exported to more than 30 countries and regions in Asia, Europe and America.
We always adhere to the "high quality and low price, honest and trustworthy" business philosophy, to provide quality products and perfect services for new and old customers.
Packing Details:1.Plastic tube: 10pcs/tube or 5pcs/tube+Carton.
2.Single box: plastic bag+single box+Carton.
3.Package as your requirement.
Delivery Details:1.Small order:by express, DHL,FEDEX,TNT,EMS, ARAMEX, AIR,etc.
2.Big order: by sea shipping
3. Time:in 2-25 days after receipt the payment and according to the order quantity.
1.High speed, High Precision, Low Noise, Long Service Life
2.Wide Array of Applications
3.Large Inventories
4.Small order accept
5.Competitive Prices and High Quality
6.Require little maintenance
7. OEM is supported
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is
according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
